RMS251B 2U Rackmount Computer

Features:

  • 2U Rack Mount Industrial Computer.
  • Backplane type.
  • 2 x Full Size Slots, 3 x Half Size Slots
  • Front Connector: 2 x USB Ports, 1 x PS/2 Port
  • Single Door with two thumbscrews, Inside Front Panel Washable Air Filter
  • 3 x 80mm Cooling Fans
  • 3 x Drive bays (2 x 3.5" Hot-swap drive bays; 1 x Slim optical drive bay).
  • 17.7" Depth Rack Mount PC.


The RMS251B rack mount industrial computer series is a 2U low profile industrial rack mount computer that is RoHS compliant design for high density rack mount PC applications. It offers flexibility and a wide range of applications including web server farm, data centers, industrial control and server applications.

The 2U system is based on a PICMG single board computer that plugs into a passive backplane. The unique backplane design provides five expansion slots after the SBC is installed.

Ample storage drive space and efficient system ventilation through three cooling fans makes RMS251B ideal for applications within the networking sector, such as Traffic Management, Firewall, Internet Gateway, Web Server, Security Server, etc.

Need a custom solution not offered online? Click the button below

Search Filter Clear All

Form FactorProcessorChipsetMemory

Base Configurations

Model: PICMG1.3 SBC Rackmount Computer - RMS251B

-
2U Rackmount With SBCQ1703AL Single Board Computer New


  • 4 Slot Backplane
  • Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
  • Up to Intel® Core i7 Processor
  • Intel Q170 Chipset
  • 8GB DDR4 2400MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,215.00

Customize

2U Rackmount With SBCOC3AL Single Board Computer


  • 4 Slot Backplane
  • Intel® Celeron® 2980U processor, SBCOC3AL-2980U
    Intel® Core™ i5-4300U Processor, SBCOC3AL-4300U (Optional)
    Intel® Core™ i7-4650U Processor SBCOC3AL-4650U (Optional)
  • SoC Integrated
  • 4GB DDR3L 1600MHz SO-DIMM Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,005.00

Customize

2U Rackmount With SBC2363EL Single Board Computer New


  • 4 Slot Backplane
  • Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
  • Up to Intel® Xeon® processor E3-1200 v5 Series Processor
  • Intel C236 Chipset
  • 8GB DDR4 Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Base Price:

$1,305.00

Customize

2U Rackmount With SBC2263EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel® Xeon® E3-1200 v3 Series Processor
  • Intel® C226 Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • nVidia Geforce 8400GS 1GB PCIe x16 Video Card
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Base Price:

$1,355.00

Customize

2U Rackmount With SBC2163EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G2030 (3M Cache, 3.0 GHz)
  • Up to Intel® Xeon® E3-1200 v2 Series Processor
  • Intel C216 PCH Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,575.00

Customize

2U Rackmount With SBCQ873EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G3220 (3M Cache, 3.0 GHz)
  • Up to Intel Core i7 Processor
  • Intel® Q87 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video and Audio
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Old Price:

$1,239.00

Base Price:

$1,259.00

Customize

2U Rackmount With SBC2063EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Xeon® Processor E3-1220 v2 (8M Cache, 3.10 GHz)
  • Intel® C206 Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,539.00

Customize

2U Rackmount With SBCQ873AL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G3220 (3M Cache, 3.0 GHz)
  • Up to Intel Core i7 Processor
  • Intel® Q87 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,155.00

Customize

2U Rackmount With SBCH813EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel® H81 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,039.00

Customize

2U Rackmount With SBCQ773AL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel Q77 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,109.00

Customize

2U Rackmount With SBCQ673AL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel Q67 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,095.00

Customize

2U Rackmount With SBCH613EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel H61 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Old Price:

$1,035.00

Base Price:

$1,065.00

Customize

2U Rackmount With SBCQ453AL Single Board Computer


  • 4 Slot Backplane
  • Dual Core Intel® E2160 1.8GHz (1MB, 800MHz)
  • Up to Intel Core 2 Quad Processor
  • Intel Q45 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,125.00

Customize

2U Rackmount With SBCQ573EL Single Board Computer


  • 4 Slot Backplane
  • Intel® Pentium® Processor G6950 (3M Cache, 2.80 GHz)
  • Up to Intel® Core i7 Processor
  • Intel® Q57 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,289.00

Customize

Model: PICMG1.0 SBC Rackmount Computer - RMS251B

-
2U Rackmount With SBCH811EL Single Board Computer


  • 5 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel® H81 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,105.00

Customize

2U Rackmount With SBCH611EL Single Board Computer


  • 5 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel H61 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Old Price:

$1,045.00

Base Price:

$1,079.00

Customize

2U Rackmount With SBC9451AL Single Board Computer


  • 5 Slot Backplane
  • Dual Core Intel® E2160 1.8GHz (1MB, 800MHz)
  • Up to Intel Core 2 Duo Processor
  • Intel 945GC+ICH7R Chipset
  • 1GB DDR2 800MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,049.00

Customize

2U Rackmount With SBCD5251EL Single Board Computer


  • 5 Slot Backplane
  • Intel® Atom™ Processor D525 (1M Cache, 1.80 GHz)
  • Intel® Atom™ processor D425 (512K Cache, 1.80 GHz) (Optional)
  • Intel ICH8M Chipset
  • 2GB DDR3 SO-DIMM Memory
  • 500GB 7200RPM SATA Hard Drive
  • Slim DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 300W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$989.00

Customize
