Supermicro SuperServer 5019P-MTR w/ 4x 3.5" Drive Bays 2x 10G LAN and Redundant Power

Features:


Web Hosting, VM
Application and Data Serving
Database Applications
  • 1U Rackmount Server
  • Single Socket P (LGA 3647) supports Intel® Xeon® Scalable Processors
  • Intel® C622 Express Chipset
  • Up to 1.0TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 8x DIMM slots
  • 4x 3.5" Hot-swap SATA3 Drive Bays with RAID
  • 1x PCI-E 3.0 x16 Slot, 1x M.2 Slot
  • 2x 10GBase-T LAN Ports with Intel X772 + X557, Integrated IPMI 2.0 and KVM with Dedicated LAN
  • 1x VGA, 2x COM, 4x USB 3.0, 2x USB 2.0
  • 4x 40mm Cooling Fans
  • 400W Redundant Platinum Power Supplies w/ BBP® Option
  • 19.8" Depth Rack Mount Chassis

The Supermicro 5019P-MTR 19.8" short depth 1U Rackmount server features Intel® Xeon® Scalable Processor, supports up to 1.0TB DDR4 ECC 3DS LRDIMM Memory, built-in two 10GBase-T Ethernet LAN ports. The Supermicro SuperServer 5019P-MTR comes with four 3.5" hot-swap drive bays, four 40mm cooling fans, and is equipped with 400W redundant platinum Level power supply.

Barebone & Base Configurations

1U Supermicro Rack Mount Server With X11SPi-TF Motherboard


  • Supermicro X11SPi-TF Motherboard
  • Six-core Intel® Xeon® Bronze 3104 Processor (8.25M Cache, 1.70 GHz)
  • Intel® C622 Chipset
  • 24GB(6x 4GB) DDR4 ECC Registered Memory
  • 4x 3.5" Hot-swap Drive Bays
  • 1x Slim DVD-ROM Drive (Optional)
  • 1x 1.0TB SATA3 6.0Gb/s 7200RPM 3.5" Enterprise Hard Drive
  • Built-in Video
  • Built-in 2x 10GBase-T LAN, 1x IPMI LAN
  • 400W Redundant Power Supply, Platinum Level

Barebone Only:

$1,095.00

Configured:

$2,115.00

Customize
