Supermicro Ultra SuperServer 6029U-TR4T w/ 12x 3.5" SATA and 4x 10GBase-T LAN Ports

Features:


Virtualization, Hyperconverge Storage, Cloud Computing, High End Enterprise Server, Flexible Networking Options
  • 2U Rackmount Server
  • Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s
  • Intel® C621 Express Chipset
  • Up to 3TB ECC 3DS LRDIMM or RDIMM, up to DDR4-2666MHz; 24x DIMM slots
  • 12x 3.5" Hot-swap Drive Bays: 12 SATA3 (Optional 8 SAS3 + 4 NVMe/SAS3)
  • 1x PCI-E 3.0 x16 Full-Height 10.5" Length Slots
    5x PCI-E 3.0 x8 Full-Height 10.5" Length Slots
    1x PCI-E 3.0 x8 Low Profiles Slot, 1x PCI-E 3.0 x8 (Internal LP)
  • 4x 10GBase-T LAN Ports via Intel X710-BM1
  • 4x Heavy Duty 80mm Fans
  • 800W Redundant Titanium Level (96%) Power Supplies
  • 28.46" Depth Rack Mount Chassis

The Supermicro Ultra SuperServer 6029U-TR4T is an 28.46" depth 2U Rackmount server that features dual latest Intel® Xeon® Scalable Processor, up to 3TB DDR4 ECC 3DS LRDIMM, built-in four 10GBase-T Ethernet LAN ports. The 6029U-TR4T 2U Rackmount server comes with twelve 3.5" hot-swap drive bays, is equipped with four 80mm heavy duty fans, and 800W redundant Titanium level power supply.


Due to the complexity of integration, this product is sold as completely assembled systems only. Please contact our Supermicro sales rep for special requirements.

Base Configurations

2U Supermicro Rack Mount Server With X11DPU Motherboard


  • Supermicro X11DPU Motherboard
  • 2x Six-core Intel® Xeon® Bronze 3104 Processor (8.25M Cache, 1.70 GHz)
  • Intel® C621 Chipset
  • 48GB(12x 4GB) DDR4 ECC Registered Memory
  • 12x 3.5" Hot-swap Drive Bays
  • 1x 1.0TB SATA3 6.0Gb/s 7200RPM 3.5" Enterprise Hard Drive
  • Built-in Video
  • Built-in 4x 10GBase-T LAN Ports via AOC-2UR66-I4XTF-P Add-on Card (Intel X710-BM1)
  • 800W Redundant 80 Plus Titanium Power Supply

Configured:

$3,745.00

Customize
