Supermicro CloudDC SuperServer 621C-TN12R

Features:


Web Server, Firewall Application
Data Center Optimized, Value IaaS
Cloud Computing, Compact Server
DNS & Gateway Servers, Firewall Application
CDN, Edge Nodes
  • 2U Rackmount Server
  • Dual Socket E (LGA-4677) 4th/5th Gen Intel® Xeon® Scalable processors
  • Intel® C741 Chipset
  • 16x DIMMs up to 4TB 3DS ECC DDR5-5600: RDIMM
  • 12x 3.5/2.5" hot-swap hybrid NVMe/SATA/SAS drive bays
  • 4x PCIe 5.0 x8 FHHL (optional: combine into 2 PCIe 5.0 x16);
  • 2x PCIe 5.0 x16 FHHL
  • 2x PCIe 5.0 x4 NVMe M.2
  • 2x AIOM (OCP 3.0) slots with NCSI for networking, 1x dedicated IPMI LAN
  • 1x VGA, 1x COM, 2x USB 3.0 (rear)
  • 3x 80mm heavy duty fans with optimal fan speed control, 1 air shroud
  • 1200W redundant Titanium level 100-240Vac and 200-240 Vdc power supplies
  • 25.5" Depth Rack Mount Chassis

The Supermicro CloudDC SuperServer 621C-TN12R 2U 25.5" depth Rackmount server features dual socket 4th/5th Gen. Intel® Xeon® Scalable Processor. Supports 16x DDR5 ECC RDIMM slots, 2x PCIe 5.0 x4 NVMe M.2, 2x PCIe 5.0 x16 and 4x PCIe 5.0 x8 slots, dual AIOM (OCP 3.0) slots with NCSI for networking and one dedicated IPMI LAN port. The Supermicro Server 621C-TN12R comes with 12x 3.5/2.5" hot-swap NVMe/SATA/SAS drive bays, 3x 80mm heavy duty fans, and is equipped with 1200W redundant titanium level power supply.
