Gigabyte Server E263-S30 (rev. AAD1) 4th/5th Gen Intel® Xeon® Scalable Server System
Features:
- 2U Rack Mount Server
- Supports up to 2 x Dual slot Gen5 GPUs
- 4th/5th Gen Intel® Xeon® Scalable Processors
- Single processor, LGA 4677
- Intel® Xeon® CPU Max Series
- 8-Channel RDIMM DDR5 per processor, 16 x DIMMs
- Dual ROM Architecture
- 2 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays on rear side
- 1 x M.2 slot with PCIe Gen3 x4 interface
- 2 x FHFL PCIe Gen5 x16 slots for GPUs
- 2 x OCP 3.0 Gen5 x16 slots
- 1 x 1Gb/s LAN port (Intel® I210-AT), 1 x Dedicated management port
- 4 x 80x80x38mm (18,300rpm) Cooling Fans
- 1600W 80 PLUS Platinum redundant power supply
- Application: AI, AI Training, AI Inference, Visual Computing, Networking, Edge & Hybrid/Private Cloud Server
The Gigabyte Server E263-S30 (Rev. AAD1) 2U Rackmount Server features single socket 4th/5th Gen Intel® Xeon® Scalable Processors, 16x DDR5 ECC RDIMM slots. The E263-S30 (Rev. AAD1) supports up to 2 x dual slot Gen5 GPUs, comes with 2 x 2.5" NVMe/SATA/SAS hot-swappable bays on rear side, is equipped with 4x 80mm cooling fans, and 1600W 80 Plus platinum redundant power supply.
Lowest Price Guaranteed on Complete Systems. Please Ask Sales for Details.
Base Configurations
Gigabyte E263-S30 (rev. AAD1) 2U Rackmount Server
4th/5th Gen Intel® Xeon® Scalable Processors
DDR5 ECC Registered Memory
2 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
1 x TPM Header
1 x Mini-DP Port
2 x OCP 3.0 Slots
Built-in 1 x GbE LAN, 1 x Management LAN
1600W Redundant 80 Plus Platinum Power Supply
