HTB-150-N6210 Medical Embedded System

Features:

  • Intel® Celeron® Processor N6210 (code name: Elkhart Lake)
  • On-board LPDDR4x 8GB Memory
  • On-board eMMC 32GB Storage
  • 1 x M.2 2280 M key slot (PCIe), 1 x M.2 2230 A key slot (PCIe + USB)
  • 4 x USB 3.2 Gen 2
  • Fanless Embedded System

The HTB-150-N6210 palm-sized medical embedded system is a compact and efficient solution engineered to meet the rigorous demands of medical environments. Powered by the Intel® Celeron® Processor N6210 (code name: Elkhart Lake), it ensures reliable performance while maintaining energy efficiency. Its fanless design enhances reliability and reduces maintenance requirements, making it suitable for noise-sensitive medical settings. With 4 x USB 3.2 Gen 2 ports, it offers high-speed connectivity for peripheral devices, facilitating efficient data transfer and device integration. The on-board eMMC 32GB storage and on-board LPDDR4x 8GB memory provide ample storage and memory capacity for medical applications and data processing needs. Compact yet powerful, the HTB-150-N6210 is an ideal solution for space-constrained medical environments where reliability, performance, and connectivity are crucial.

Base Configurations

HTB-150-N6210 Medical Embedded PC

  • Intel® Celeron® Processor N6210 (1.5M Cache, 1.20 GHz)
  • On-board 8GB Memory
  • On-board eMMC 32GB Storage
  • 1 x RS-232
  • 4 x USB 3.2
  • 1 x HDMI
  • 1 x M.2 M Key 2280, 1 x M.2 A Key 2230
  • 2 x GbE LAN
  • 65W Medical Grade Power Adapter

Configured:

$619.00

Customize
