RMS575B 4U Rackmount Computer

Features:

  • 4U rack mount industrial computer.
  • 5 drive bays (3 x 5.25" and 2 x 3.5" drive bays).
  • 14 slot backplane.
  • 17.7" deep rack mount pc.


The RMS-575 rack mount industrial computer is designed for industrial control and server applications in harsh industrial environments. The chassis is constructed of 18-gauge steel for ruggedness and corrosion resistance. A lockable-shielded door protects and affords easy access to the drives. Filtered ventilation fans prevent airborne dust particles from being drawn into the chassis.

Internally, RMS-575 rack mount industrial computer chassis is equipped with five drive bays, three 5.25", one 3.5" drives are front accessible, one 3.5" drive is internal. A card retention system is included to securely hold add-on cards in their slots. Plus, hot-swapped serial ATA or ultra SCSI removable kit can be easier added on the drive bays.

The RMS-575 rack mount pc supports standard 14-slot passive backplane with a single board computer . With this kind of versatility, the RMS-575 rack mount pc can be customized for powerful industrial workstation and is ideal for high-density web server, back office server, firewall, proxy server and VPN gateway applications including collocation.

Need a custom solution not offered online? Click the button below

Search Filter Clear All

Form FactorProcessorChipsetMemory

Base Configurations

Model: PICMG1.3 SBC Rackmount Computer - RMS575B

-
4U Rackmount With SBCQ1703AL Single Board Computer New


  • 14 Slot Backplane
  • Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
  • Up to Intel® Core i7 Processor
  • Intel Q170 Chipset
  • 8GB DDR4 2400MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,089.00

Customize

4U Rackmount With SBCOC3AL Single Board Computer New


  • 14 Slot Backplane
  • Intel® Celeron® 2980U processor, SBCOC3AL-2980U
    Intel® Core™ i5-4300U Processor, SBCOC3AL-4300U (Optional)
    Intel® Core™ i7-4650U Processor SBCOC3AL-4650U (Optional)
  • SoC Integrated
  • 4GB DDR3L 1600MHz SO-DIMM Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$879.00

Customize

4U Rackmount With SBC2363EL Single Board Computer New


  • 14 Slot Backplane
  • Intel® Pentium® Processor G4400 (3M Cache, 3.30 GHz)
  • Up to Intel® Xeon® processor E3-1200 v5 Series Processor
  • Intel C236 Chipset
  • 8GB DDR4 Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Base Price:

$1,179.00

Customize

4U Rackmount With SBC2263EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel® Xeon® E3-1200 v3 Series Processor
  • Intel® C226 Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • nVidia Geforce 8400GS 1GB PCIe x16 Video Card
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Base Price:

$1,235.00

Customize

4U Rackmount With SBC2163EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Xeon® Processor E3-1220 v2 (8M Cache, 3.10 GHz)
  • Intel® C216 PCH Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,449.00

Customize

4U Rackmount With SBC2063EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Xeon® Processor E3-1220 v2 (8M Cache, 3.10 GHz)
  • Intel® C206 Chipset
  • 8GB DDR3 1600MHz ECC Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,415.00

Customize

4U Rackmount With SBCQ873AL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G3220 (3M Cache, 3.0 GHz)
  • Up to Intel Core i7 Processor
  • Intel® Q87 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,029.00

Customize

4U Rackmount With SBCQ873EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G3220 (3M Cache, 3.0 GHz)
  • Up to Intel Core i7 Processor
  • Intel® Q87 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video and Audio
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply
  • IPMI 2.0 Compliant iRIS-2400 Module (Optional)

Old Price:

$1,109.00

Base Price:

$1,135.00

Customize

4U Rackmount With SBCH813EL Single Board Computer New


  • 14 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel® H81 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$915.00

Customize

4U Rackmount With SBCQ773AL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel® Core i7 Processor
  • Intel® Q77 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$989.00

Customize

4U Rackmount With SBCQ673AL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel® Core i7 Processor
  • Intel® Q67 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$969.00

Customize

4U Rackmount With SBCH613EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel® Core i7 Processor
  • Intel® H61 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$945.00

Customize

4U Rackmount With SBCQ573EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G6950 (3M Cache, 2.80 GHz)
  • Up to Intel® Core i7 Processor
  • Intel® Q57 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$1,165.00

Customize

4U Rackmount With SBCQ453AL Single Board Computer


  • 14 Slot Backplane
  • Dual Core Intel® E2160 1.8GHz (1MB, 800MHz)
  • Up to Intel Core 2 Quad Processor
  • Intel Q45 Chipset
  • 4GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$999.00

Customize

Model: PICMG1.0 SBC Rackmount Computer - RMS575B

-
4U Rackmount With SBCH811EL Single Board Computer New


  • 14 Slot Backplane
  • Intel® Celeron® Processor G1840 (2M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel® H81 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$919.00

Customize

4U Rackmount With SBCH611EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Pentium® Processor G640 (3M Cache, 2.80 GHz)
  • Up to Intel Core i7 Processor
  • Intel H61 Chipset
  • 2GB DDR3 1600MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Old Price:

$859.00

Base Price:

$895.00

Customize

4U Rackmount With SBC9451AL Single Board Computer


  • 14 Slot Backplane
  • Dual Core Intel® E2160 1.8GHz (1MB, 800MHz)
  • Up to Intel Core 2 Duo Processor
  • Intel 945GC+ICH7R Chipset
  • 1GB DDR2 800MHz Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVDRW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$865.00

Customize

4U Rackmount With SBCD5251EL Single Board Computer


  • 14 Slot Backplane
  • Intel® Atom™ Processor D525 (1M Cache, 1.80 GHz)
  • Intel® Atom™ processor D425 (512K Cache, 1.80 GHz) (Optional)
  • Intel ICH8M Chipset
  • 2GB DDR3 SO-DIMM Memory
  • 500GB 7200RPM SATA Hard Drive
  • 24x SATA DVD+/-RW Optical Drive
  • Built-in Video
  • Built-in Dual Gigabit LAN
  • 400W PS/2 ATX PFC 110/220 VAC Power Supply

Base Price:

$805.00

Customize
