Supermicro Storage SuperServer 610P-ACR12N4H

Features:

Database Applications
Hyperscale Data Center
Object Storage
Big Data Analytics
Scale-Out Density
Hadoop & Ceph storage solutions
cale-out NAS
  • 1U Rackmount Server
  • Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors Support CPU TDP 120-205W
  • Intel® C621A Chipset
  • Up to 4TB ECC DDR4-3200: LRDIMM/RDIMM
  • 12x Hot-swap 3.5" SAS/SATA Drive Bays
    4x Hot-swap EDSFF Short Bays, 2x 2.5" 7mm NVMe/Hot-Swap SATA Drive Bays
    4x E1.S (EDSFF Short) NVMe Drives
  • RAID support via Broadcom® 3916
  • PCI-E 4.0 x16 AIOM Support + 3 PCI-E 4.0 LP Slots
  • 2x 25Gb SFP28 onboard Front LED Indicator for each drive
  • 6x 40mm Heavy Duty Fans
  • 800W Redundant Platinum Power Supply
  • 37” Depth Rack Mount Chassis

The Supermicro Storage SuperServer 610P-ACR12N4H 1U 37” depth Rackmount server features dual 3rd Gen. Intel® Xeon® Scalable Processor, up to 4.0TB DDR4 RDIMM/LRDIMM memory, two M.2 slots and two 25G SFP+ port onboard. The Supermicro Server 610P-ACR12N4H comes with 12x 3.5" hot-swap SATA3/SAS3 drive bays with RAID support via Broadcom® 3916, 4x E1.S NVMe drives, 2x 2.5" NVMe/SATA hot-swap drive bays, 6x 40mm heavy duty fans, and is equipped with 800W redundant platinum level power supply.
