IFB122 Robust RISC-based DIN-rail Embedded Computer


  • Freescale i.MX 6UL processor, ARM® Cortex®-A7 @ 528 MHz
  • 256 MB DDR3 Onboard Memory
  • 4GB eMMC Flash Onboard
  • 1x Wireless (Wi-Fi or 3G/4G)
  • 2x Digital Inputs and 1x Digital Output
  • 9 ~ 48 VDC Wide Range Power Input with Terminal Block
  • Embedded Linux Operating System (Yocto)
  • Fanless Design
  • Wide Operating Temperature range from -40°F to +158°F

The IFB122 is an Embedded PC with a Freescale i.MX 6UL processor, ARM Cortex®-A7 at 528 MHz and 256MB of onboard DDR3 memory. It is constructed of extruded aluminum and heavy-duty steel and has an IP30 rating. It's dimensions are 1.22" x 3.94" x 4.92" and temperature of operation is -40°F ~ +158°F. The IFB122 can handle vibrations of 2G @ 5~500MHz and amplitude to 0.35ms.

There is an eMMC 4 GB Flash onboard as well as a SIM card and a PCI Express Mini card. The IFB122 has two RS-232/422/485 one USB 2.0, two 10/100 Mbps and a DIO (2-IN/ 1-OUT). It accepts 9-48VDC as it's power source and can be mounted on a Din-rail.

Base Configurations

IFB122 Robust Din-rail Fanless Embedded Computer

  • Freescale i.MX 6UL processor, ARM┬« Cortex┬«-A7 @ 528 MHz
  • 256 MB DDR3 Onboard Memory
  • 4GB eMMC Flash Onboard
  • 2 x RS-232/422/485
  • 1x DIO (2-IN/1-OUT)
  • 1x USB2.0 Port
  • 1x PCI Express Mini Card Socket, 1 x SIM Card Socket
  • 2x GbE LAN Ports
  • 9~48 VDC Power Input
