MPC103-845 - 10.1" WXGA TFT Fanless Medical Grade Touch Panel Computer

Features:

  • 10.1” WXGA TFT LCD Display with LED Backlight
  • Fanless Design with Intel® Celeron® N3060 Processor
  • 1 x 204-pin DDR3L-1600 MHz SO-DIMM, (Max. 8GB)
  • 2 x GbE LANs, 4 x USB and 2 x COM
  • External AT/ATX Mode Selection Switch
  • Easy Access Storage Design
  • Supports RFID (Optional)
  • Adjust RS-232/422/485 Setting via BIOS
  • IP65 Plastic Front Bezel
  • 4th EN 60601-1 (ESD contact 8KV, air 15KV), CE and FCC
  • Supports Panel Mount, Wall Mount, VESA Arm, Desktop Stand (Optional)


The MPC103-845 is a Fanless panel PC for medical applications. The system is powered by the Intel Celeron N3060 processor and comes equipped with a 10.1-inch WXGA TFT LCD display with a projected capacitive touch screen and 350 nits of brightness. The system is capable of a wide variety of applications including integration into a nursing cart, point-of-care terminal or patient infotainment terminal.

Its thickness of 38mm and weight of 1.08kg make it easy to install in a broad range of environments with limited space; also the round corner design can avoid scratches while in use. In addition, since the MPC103-845 is Fanless, it offers silent operations for noiseless environments. The multi-touch screen also minimizes peripherals and wiring. To ensure operational safety, the MPC103-845 has passed EN60601-1, CE, FCC Class B certifications.

Barebone & Base Configurations

MPC103-845 Medical Panel PC

  • 10.1" 1280x800 350 nits TFT LCD w/ Projected Capacitive Multi-touch Screen
  • Intel® Celeron® N3060 Processor (2M Cache, 1.60 GHz)
  • 2GB DDR3L SO-DIMM Memory
  • 32GB Flash Disk; MSATA SATAIII Interface , MLC, 32°F~158°F
  • 1 x RS-232 (DB9), 1 x RS-232/422/485 (DB9)
  • 2 x USB 3.0, 2 x USB 2.0 Ports
  • 2 x Gigabit Ethernet Ports
  • 1 x Full-size PCIe Mini Card Slot with mSATA
    1 x Full-size PCIe Mini Card Slot with SIM
  • Wireless Module (Optional)
  • 9~36VDC Terminal Block Connector with Over Current Protection Fuse
  • 65W 100~240V AC-DC Power Adapter(Optional)

Barebone Only:

$829.00

Configured:

$859.00

Customize
