MPC152-845 15" Medical Panel PC

Features:

  • 15" XGA TFT LCD Display with LED Backlight
  • IP65, NEMA 4 Rugged Protection, Plastic Front Bezel
  • Fanless design with Intel® Celeron® N3060 Processor
  • 1 x 204-pin DDR3L-1600 MHz SO-DIMM, (Max. 8GB)
  • 2 x GbE LANs, 4 x USB and 2 x COM
  • External AT/ATX Mode Selection Switch
  • Easy Access Storage Design
  • Supports RFID (Optional)
  • Supports Panel Mount/Wall Mount/VESA Arm/ Desktop Stand (Optional)
  • Adjust RS-232/422/485 Setting via BIOS
  • 4th EN 60601-1 (ESD contact 8KV, air 15KV), CE and FCC


The MPC152-845 is a Fan-less Panel PC that supports Intel's Celeron processor N3060 (up to 2.48 GHz) and up to a maximum of 8GB 204-pin SO-DIMM DDR3L-1600. The 15" XGA TFT offers 420 nits at a resolution of 1024 x 768. It also incorporates a Resistive type touch screen housed behind the front bezel, which is IP65 and offers NEMA 4 rugged protection. Internally there is sufficient room for a single 2.5" SATA HDD. There is also one full-size PCI Express Mini Card slot with mSATA and another with SIM. The MPC152-845 is 15.27" x 2.14" x 12.11" and can be mounted by VESA arm, Panel mount, Desktop stand and Wall mount.

There are one RS-232 COM Port, one RS-232/422/485 Selectable COM Port, two USB 2.0 and two USB 3.0; There is also two Ethernet Ports. The MPC152-845 comes in an AC version that which uses a 100~240V AC-DC 65W power adapter or a DC version which accepts 9~36VDC with an over current protection fuse.

Barebone & Base Configurations

MPC152-845 Medical Panel PC

  • 15" 1024x768 420 nits TFT LCD w/ Resistive Touchscreen
  • Intel® Celeron® N3060 Processor (2M Cache, 1.60 GHz)
  • 2GB DDR3L SO-DIMM Memory
  • 500GB 5.4KRPM 2.5" SATA Hard Drive
  • 1 x RS-232 (DB9), 1 x RS-232/422/485 (DB9)
  • 2 x Gigabit Ethernet Ports
  • 2 x USB 3.0, 2 x USB 2.0 Ports
  • 1 x Full-size PCIe Mini Card Slot with mSATA
    1 x Full-size PCIe Mini Card Slot with SIM
  • 1 x 8-bit DIO (Programmable, DB9)
  • Built-in Audio (Line-out)
  • Wireless Module (Optional)
  • 9~36VDC Terminal Block Connector
  • 65W 100~240V AC-DC Power Adapter (Optional)

Barebone Only:

$1,029.00

Configured:

$1,075.00

Customize
