PMS8150 15" Fanless Industrial Panel PC
Features:
- 15" 1024 x 768 350nits XGA TFT LCD with Resistive Touch Screen
- Intel Celeron Processor J6412 1.5M Cache, up to 2.60 GHz / TDP 10W
- 8GB16GB/32GB DDR4 Memory
- 1 x M.2 M key 2242/2280 (PCIe Gen3 x2), 1 x M.2 B key 3024, 1 x M.2 E Key 2230
- 2 x HDMI
- 2 x COM, 2 x 2.5GbE LAN
- Panel Mount and VESA Mount (Optional)
- IP65 Compliant Front Panel
- CE, UKCA, FCC, VCCI, Shock, Vibration
.
Base Configurations
PMS8150 15.6" Fanless Touch Panel PC
- 15" 1024 x 768 350nits XGA TFT LCD Panel w/ Resistive Touch Screen
- Intel Celeron Processor J6412 (1.5M Cache, up to 2.60 GHz)
- 8GB DDR4 Memory
- 16GB/32GB DDR4 Memory (Optional)
- 500GB M.2 Solid State Drive
- 1 x RS-232 (DB9), 1 x RS-232/422/485 (DB9)
- 2 x 2.5GbE LAN
- 3 x USB3.2, 2 x USB2.0
- 2 x HDMI
- 1 x M.2 B-key 3024 USB3.1/USB2.0 Interface
- 1 x M.2 E-key 2230 USB2.0/PCIe Gen3 x1 Interface
- Power Adapter (Optional)
Configured: |
$1,325.00 |
