ASUS RS500A-E11-RS12U 1U Rackmount Server
Features:
- 1U Rack Mount Server
- AMD LGA 4094 CPU Socket
- Supports 3rd Gen AMD EPYC™ processors with AMD 3D V Cache™ technology (up to280W)
- 16 x DDR4 3200/2933 RDIMM/LRDIMM/LRDIMM 3DS (Max. 4TB)
- 12 x Hot-Swap 2.5" SATA/SAS/NEMe Drive Bays
Optional 4 x 2.5" SATA/NEMe Drive Bays - 1 x PCIe 4.0 x 16 (FH, HL), 1 x PCIe 4.0 x 16 (LP, HL), 1 x PCIe 4.0 x8 (LP, HL), 1 x OCP 3.0 Mezzanine Socket
- 2 x M.2 Socket (Gen4 x4 link or SATA Mode, up to 22110 Module)
- TPM SPI Module (Optional)
- PFR Module (Optional)
- Rear I/O Ports: 2 x USB 3.2, 2 x GbE LAN, 1 x Management LAN, 1 x VGA, 1 x COM
- Dimension: 33.15" x 17. 68" x 1.73" (842mm x 449mm x 44mm
The ASUS RS500A-E11-RS12U is a versatile 1U server powered by Powered by AMD EPYC 7003 processor with 64 cores, 128 threads and support for a maximum TDP of up to 280 watts per socket. For storage capabilities the RS500A-E11-RS12U has Up to 12 all-flash NVMe drives on front panel and four drives on middle panel enable high-throughput performance. For expansion purposes there are up to three PCIe® 4.0 slots. Additional features include a tool-less design for easy serviceability and Integrated PFR FPGA as the platform Root-of-Trust solution.
