Features:

• 15.6" 1920 x 1080 450 nits FHD Display with Projected Capacitive Multi-touch Screen
• Anti-UV / Anti-glare Coating, Support Gloves, Surface Hardness: ?7H
• 304 Stainless Steel Housing
• Full Body IP66 Rate with M12 Fully Waterproof Interface
• Intel Atom X7433RE / X7835RE Processor
• 1 x SO-DIMM DDR5-4800 up to 16GB (Pre-installed 8GB)
• 1 x M.2 M-Key 2280 (PCIe Gen3 x2)
• High-speed Transmission Fiber Optic Module (Optional)
• WiFi 6E and Bluetooth 5.2 (Optional)
• 10~28V Wide Voltage Input
• Wide Operating Temperature Range: -22°F to +131°F

The SHIELD-156 is a versatile 15.6-inch stainless steel panel PC designed for industrial applications requiring a balance of performance and compact size. Powered by an Intel Atom x7 processor (up to 3.4 GHz) with DDR5-4800 RAM (up to 16GB, ECC supported) and M.2 SSD storage, it delivers reliable computing power. Its full HD (1920x1080) 450-nit LCD features PCAP touch (anti-UV/AR coating) and is housed in an IP66-rated enclosure, capable of operating in harsh conditions (-30°C to 55°C). Connectivity includes dual 2.5GbE LAN, Wi-Fi 6E/BT 5.2 (optional), RS-232/422/485, CAN bus, GPIO, USB 3.2 Gen1, and VGA for legacy support. Additional options include a wide-angle camera, 128GB eMMC, and expandability via M.2 slots. Certified for CE/FCC Class A, it supports wide-range DC 10-28V power and VESA/yoke mounting, making it ideal for industrial automation, transportation, and control systems in demanding environments.
