TANK-880-Q370 Fanless Embedded PC with 8th/9th Generation Intel® Core™ Processor 4x Expansion Slots

Features:

    8th/9th Gen Intel® Core™ processor Platform
  • Intel® Q370 chipset
  • 2 x 260-pin DDR4 SO-DIMM Memory (Max. 64GB)
  • Four Accessible 2.5” HDD/SSD SATA 6 Gb/s Bay (with RAID 0/1/5/10 Support)
  • Dual Independent Displays with High Resolution Support
  • Rich High-speed I/O Interfaces
  • On-board Internal Power Connector for Providing Power to Add-on Cards
  • Great Flexibility for Hardware Expansion

The TANK-880-Q370 is a Fanless embedded system, which supports the 8th and 9th generation Intel processors. The internal hardware is configured with a Q370 chipset to complement the available processors and utilized DDR4 SO-DIMM memory up to a maximum capacity of 64 GB. The system is constructed with dual independent displays, both of which can support high resolutions in case the user required multiple screens for their application. The I/O interface provided also supports high speeds, which apply to all available COM ports, USB ports etc. Card Add-ons can be utilized with ease since the internal motherboard provides an on-board power connector.

In terms of storage space, there are four accessible 2.5" hard drive bays. Since the system supports RAID configurations, the four slots would allow RAID support 0, 1, 5, and 10 RAID configurations.

Barebone & Base Configurations

TANK-880-Q370 Fanless Embedded PC Configurations

  • Model: TANK-880-Q370-i5R/8G/4A-R10
  • Intel® i5-9500TE 2.2GHz, (up to 3.6GHz, 6-core, TDP 35W)
  • 8GB DDR4 SO-DIMM Memory
  • 1.0TB SATA 2.5" Hard Drive
  • 2 x 2280 M Key, 1 x 2230 A Key
  • 3 x RS-232/422/485 (DB-9 w/ 2.5 kV Isolation)
  • 6 x USB 3.2
  • Expansion Slots: 1 x PCIe x16, 2 x PCIe x4, 1 x PCIe x1
  • 1 x Full-size PCIe Mini Slot (PCIe/ USB 2.0/ SATA)
  • 8-bit Digital I/O, 4-bit Input/4-bit Output
  • Built-in HDMI, DP and Audio
  • Built-in 3x Gigabit LAN
  • TPM 2.0 Module (Optional)
  • 9~36V DC Power Connector
    150W 90~264VAC Power Adapter (Optional)

Barebone Only:

$1,535.00

Configured:

$1,609.00

Customize

TANK-880-Q370 Fanless Embedded PC Configurations

  • Model: TANK-880-Q370-i7R/8G/4A-R10
  • Intel® i7-9700TE 1.8GHz, (up to 3.8GHz, 8-core, TDP 35W)
  • 8GB DDR4 SO-DIMM Memory
  • 1.0TB SATA 2.5" Hard Drive
  • 2 x 2280 M Key, 1 x 2230 A Key
  • 3 x RS-232/422/485 (DB-9 w/ 2.5 kV Isolation)
  • 6 x USB 3.2
  • Expansion Slots: 1 x PCIe x16, 2 x PCIe x4, 1 x PCIe x1
  • 1 x Full-size PCIe Mini Slot (PCIe/ USB 2.0/ SATA)
  • 8-bit Digital I/O, 4-bit Input/4-bit Output
  • Built-in HDMI, DP and Audio
  • Built-in 3x Gigabit LAN
  • TPM 2.0 Module (Optional)
  • 9~36V DC Power Connector
    150W 90~264VAC Power Adapter (Optional)

Barebone Only:

$1,695.00

Configured:

$1,775.00

Customize
